Lesson 9.1. Syntax of C arrays

Introduction

An array is a sequential sequence of cells, all of the same type. An array can have one or more dimensions. Here is an example of a declaration of an 5 cells integer array:

int tab[5];

An array can only contain cells of the same type. If you need to create an array that contains cells of different types (e.g. integers and floats), you have to create two arrays or use structures that we will see later in this course.

Syntax

The syntax for the declaration of an array is illustrated below:

This statement creates a table that can be represented as rows or columns:

$$tab = \begin{bmatrix} a_0 && a_1 && a_2 && a_3 && a_4 \end{bmatrix}$$

$$tab = \begin{bmatrix} a_0 \\ a_1 \\ a_2 \\ a_3 \\ a_4 \end{bmatrix}$$

The numbering of the cells starts at zero. A table of n cells is numbered from 0 to n-1.

Cell access

An element of the array can be accessed in read or write mode by using the name of the array followed by the indices between square brackets. For example:

// Declares an array of 5 integers
int tab[5];

// Assign 2 in the first cell
tab[0] = 2;

// Assign 12 to the last cell
tab[4] = 12;

// Check if there is 12 in the last cell
if (tab[4] == 12) printf ("OK\n");

Note: it is not possible to perform assignment or comparison operations on a table as a whole.

• if (tab1==tab2) does not compare arrays
• tab1=tab2 does not copy tab2 in tab1

To compare two arrays or copy one array into another, you must do it cell by cell.

Exercises

Exercise 1

Write a program that creates an array of 10 cells and displays its contents (without initializing it). The display must be done with a loop according to the following example:

tab[0] = -309253648
tab[1] = 32550
tab[2] = 0
tab[3] = 0
tab[4] = 4195664
tab[5] = 0
tab[6] = 4195328
tab[7] = 0
tab[8] = 609240816
tab[9] = 32765


Exercise 2

Using the code from exercise 1, write a loop that initializes the first cell of the array with -1, the second with -2 and so on:

tab[0] = -1
tab[1] = -2
tab[2] = -3
tab[3] = -4
tab[4] = -5
tab[5] = -6
tab[6] = -7
tab[7] = -8
tab[8] = -9
tab[9] = -10


Quiz

In C, an array ...

How many cells are in the following array?

float tab[12];

**What is the size in memory of the following array ? We will suppose that the float type is encoded on 4 bytes.

float tab[4];

Consider the following array. Which of the following statements are correct?

char tab[4];

Which code copies table 2 into table 1?

int tab1[100];
int tab2[100];

Assuming the existence of an array of 10 cells, tab[1] corresponds to ... ?
